Presentata la nuova Citroen DS3 R3

La Citroen Racing, vincitrice di 5 titoli Costruttore nel WRC, ha presentato oggi al pubblico la nuova Citroen DS3 R3 che debutterà ufficialmente verso la fine del 2010. Versatile, performante e con un prezzo accessibile, la DS3 R3 è destinata a divenire il nuovo leader della categoria.

La nuova Citroen DS3 R3 è costruita secondo il regolamento FIA per le Gruppo R3T, ha la stessa struttura delle vetture di serie, con la struttura dell’abitacolo rinforzata e rollbar multipoint. Sotto il cofano c’è un 4 cilindri di 1.6 litri THP ( turbo ad alta pressione ) che è stato sviuppato sulla base del propulsore PSA. Tutto è stato scelto con accuratezza per far arrivare la vettura ad una potenza di 210bhp. In aggiunta alla potenza massima è stata posta particolare attenzione alla coppia per migliorare la trazione, ben 350Nm.

La DS3 R3 vanta tutta l’esperienza della Citroen nel WRC, come la Citroen C4 WRC è equipaggiata con un cambio a sei rapporti semi automatico con controllo sequenziale, che permette di cambiare marca due volte piu’ velocemente di un cambio manuale.

Il sistema di sospensioni usa la piu’ recente tecnologia ed è stato costruito per adattarsi a tutte le superfici stradali, dalla terra all’asfalto. C’è un’ampia varietà di setup predefiniti, che rendono la Citroen DS3 R3 adatta a tutti gli stili di guida. La Citroen Racing raccomanda di montare gomme BFGoodrich sulla Citroen DS3 R3.

La Citroen Racing parla di prezzo accessibile per questa vettura, ma non ci sono ancora informazioni precise in merito.

Altre foto della Citroen DS3 R3

Specifiche tecniche

COMPOSITION OF THE DS3 R3 KIT
(Marketed by Citroën Racing for assembly on a DS3 THP 150)

TARMAC RACING KIT (500 PARTS)
– Racing engine, assembled and bench-tested, ready to be mounted
– Gearbox, assembled and bench-tested, ready to be mounted
– Reinforced body shell, with roll-cage and seat attachment brackets and accessories (handbrake, ECUs, spare wheel, mounting brackets)
– Reinforced engine sub-frame
– Protective skidplate for engine and exhaust
– Adjustable front and rear suspension elements
– Reinforced hub carriers
– Adjustable specific front suspension wishbones
– Maximum size front and rear brake discs
– Front and rear specific brake callipers
– Reinforced rear axle
– Set of rear axle geometry adjustment shims
– Direct power-steering rack
– Specific braking system
– Specific ‘pedal box’ assembly
– Tarmac 7×17’’ wheels
– Fuel system with FIA-homologated tank
– Specific engine and gearbox cooling system
– Air/high-capacity air exchanger and specific booster circuit
– Aviation type electrical system with digital instrument panel display
– Data acquisition system built into the injection unit
– Roof-mounted air intake
– Glossy dashboard strip
– Specific wheel arch protections
– Front and rear tow straps
– Spare wheel straps

OPTIONAL EQUIPMENT:
– Gravel rallying adaptation kit, including shock absorbers, springs, anti-roll bar, front brake discs, 6×15’’ gravel wheels and bodywork protective covers
– Short or long torque settings
– Co-driver footrest
– Citroën Racing rear-view mirrors
– FIA-homologated crash panel doors
– Xenon headlamp assembly
– 64MB data acquisition unit upgrade
– Specific mapping for racing fuel
– Tool kit, including: wheel hub fitting tool, brake fluid bleed device, steering rack shim
– Springs of varying levels of stiffness
– Anti-roll bar of varying diameters
– Standard bodywork spare parts kit

EQUIPMENT NOT INCLUDED IN THE KIT:
– Seats
– Harness
– Fire extinguishers
– Battery
– Spare wheel
– Jack and tyre-changing accessories
– Radio equipment and on-board computer
– FIA-approved anti-shatter protective film
– Tyres

TECHNICAL SPECIFICATIONS

CHASSIS
Structure Reinforced body with welded, multi-point roll cage
Bodywork DS3 THP 150 with specific roof-mounted air intake and rear-view mirrors

ENGINE
Type 1.6 THP PSA
Bore x stroke 77×85.8 mm
Capacity 1,598cc
Maximum power 210bhp at 4,750rpm
Maximum torque 35Nm at 3,000rpm
Specific output 131.4bhp/litre
Distribution Double overhead camshaft valve train
Breaker arm with adapted cam profile
Specific pistons, connecting rods, engine flywheel and camshaft
Fuel feed Direct injection
Motorized single throttle valve

CLUTCH
Type Thrust mechanism
184mm cerametallic twin-disk

TRANSMISSION
Type Front-wheel drive
Gearbox Six-speed sequential
Control Electronically controlled with steering wheel-mounted paddle
Differential Self-locking type ZF differential

BRAKES
Front Ventilated disks, 330x30mm (tarmac) and 300x30mm (gravel)
4-piston callipers
Rear 300x8mm discs
2-piston callipers
Distribution Adjustable
Handbrake Hydraulic control

SUSPENSION
Front McPherson type
Specific hinges and hub carriers
Rear H-shaped axles
Shock absorbers BOS three-track adjustable shock absorbers (low-and high-speed compression and rebound)
Adjustable hydraulic bump stop

STEERING
Type Hydraulic power-assisted steering

WHEELS
Tarmac 7×17’’ wheels
BFGoodrich 200/50/R17 tyres
Gravel 6×15’’ wheels
BFGoodrich 195/70/R15 tyres

DIMENSIONS, WEIGHT AND CAPACITIES
Length 3,948mm
Width 1,715mm
Wheel base 2,465mm
Track 1,520mm (front) – 1,490mm (rear)
Fuel tank 67 litres
Weight 1,230kg with driver pairing (regulations)
Weight distribution 64/36% (front/rear)
